functionverboseXi
prints the component vector and its values to simulation log
Extends from TransiEnt.Basics.Icons.Function.
Information
1. Purpose of model
This function is just for evaluation purposes. It writes the component names and the externally set mass fractions to the simulation log. This is helpful for a quick overview, as the massfraction in the external definition tables is set by a vector in which the order of components can't be seen directly.
2. Level of detail, physical effects considered, and physical insight
No physical effects considered.
3. Limits of validity
(no remarks)
4. Interfaces
(no remarks), just input vectors.
5. Nomenclature
(no elements)
6. Governing Equations
No governing equations.
7. Remarks for Usage
- As it just writes the input vectors into the log with no further treatment, this function might be useful in other contexts, too.
8. Validation
Not validated yet.
9. References
(no remarks)
10. Version History
Created by Jan Braune (jan.braune@tu-harburg.de), Mar 2015
Revised by Lisa Andresen (andresen@tuhh.de), Dec 2015
Inputs
| Type | Name | Default | Description |
|---|---|---|---|
| String | Names | gas names vector [nc] | |
| Real | xi_in | mass fraction vector [nc-1] |
